Product Review
This is the GWS High Frequency 8A Electronic Speed Control.
FEATURES: Forward only ESC
5-8 cell input
Extremely light weight and micro size
For motors up to 300 size
FUT rx connector
Female 2 pin BEC Connector
Bare wire leads to motor
Instructions on back of header card
Gold Heat sink
INCLUDES: One 8amp ESC
REQUIRES: Motor, Battery
SPECS: Auto Cut (v): 3.2v
BEC: 5v/1.2amp
Current: 8amp contiuous/15amp max
Weight: 10g (.35oz)
Length: 25.5mm (1")
Width: 12.5mm (.5")
Height: 9mm (.4")
COMMENTS: A small key to help distinguish GWS Speed Controls
ICS="Forward" GS="Forward" + Brake
E="lower" auto cutoff voltage of 3.2V (normal 4.2v)
S="on/off" switch (no switch="auto" on/TX activated)
F="Futaba" J rx plug
J="J/R" (Universal) rx plug
GWS
Part GWSICS300E/F
